Name: Electric Mining Truck with Long Drive Range Large Battery Capacity and Dual Motor Drive
Brand: Zhongzhi First Bus Chengdu Co., Ltd.
SKU: XZ110EV
Price: 150,100.00 USD
Availability: InStock

Casa > prodotti > Carrello minerario elettrico >

Electric Mining Truck with Long Drive Range Large Battery Capacity and Dual Motor Drive

Long Drive Range Electric Mining Truck

Large Battery Capacity Electric Mining Truck

Dual Motor Drive Electric Mining Truck

Luogo di origine:

Chengdu, Cina

Marca:

ZEVAUTO

Certificazione:

ISO, CE

Numero di modello:

XZ110EV

Contattaci

Chiedi un preventivo

Dettagli del prodotto

Nome del prodotto:

Carrello minerario elettrico

Tipo:

Zero emissione

Tipo di FULE:

Elettrico

Dimensioni (mm):

9950*3750*4200

Distanza tra le ruote ((mm):

4500+1750 mm

Trasmissione:

Trasmissione AMT a 4 velocità.6.508-1.000

Velocità massima:

40 km/h

sospensione:

Suspensione anteriore a molla oleopneumatica + molla posteriore a foglia + sospensione bilanciata ri

Sterzo:

Volante idraulico completo + volante di emergenza

Motore di guida:

Disco hub a doppio motore/Lego (facoltativo)

Sistema di sospensione:

Suspensione anteriore a molla idropneumatica/suspensione posteriore a molla a foglia

Sistema di freni:

Freno elettrico + freno a tamburo, ritardatore di corrente di vortice (facoltativo)

Potenza nominale del motore/potenza massima (kW):

Disco hub: 495/800; Lego: 500/800

Pneumatico:

16.00R25 tre stelle (Techking).

Volume del container (m³):

42 (carico piano)/45 (carico stiva)

Evidenziare:

Long Drive Range Electric Mining Truck

Large Battery Capacity Electric Mining Truck

Dual Motor Drive Electric Mining Truck

Termini di trasporto & di pagamento

Quantità di ordine minimo

Imballaggi particolari

imballaggio nudo

Tempi di consegna

25-40 giorni lavorativi

Termini di pagamento

T/T, L/C

Capacità di alimentazione

25000 unità/all'anno

PRODOTTI RELATIVI

video

Autocarro minerario elettrico da 95 tonnellate 528kWh a emissioni zero

Ottenga il migliore prezzo

video

Autocarro minerario elettrico da 125 tonnellate, 528 kWh, a emissioni zero

Ottenga il migliore prezzo

Autocarro minerario elettrico a batteria 110 tonnellate 528kWh

Ottenga il migliore prezzo

video

Camion elettrico da 110 tonnellate con batteria LFP da 528 kWh

Ottenga il migliore prezzo

Contattaci

+8613608032908

jolin@zevauto.com

Contatta ora

Descrizione del prodotto

Electric Mining Truck with Full Hydraulic Steering

Zero-emission electric mining truck featuring long drive range and large 528kWh battery capacity, designed for efficient and environmentally friendly mining operations.

Product Specifications

Attribute	Value
Product name	Electric Mining Truck
Type	Zero Emission
Fuel type	Electric
Dimensions (mm)	995037504200
Wheelbase (mm)	4500+1750
Transmission	FAST 4-speed AMT mining truck transmission. Gear: 6.508-1.000
Max speed	40km/h
Suspension	Front oleo-pneumatic spring suspension + Rear leaf spring + Reinforced balanced suspension
Steering	Full hydraulic steering + emergency steering
Drive motor	Disc hub dual-motor/Lego (optional)
Brake system	Electric brake + drum brake, eddy current retarder (optional)
Motor rated/peak power (kW)	Disk hub: 495/800; Lego: 500/800
Tire	16.00R25 three-star rating (Techking). Other brands available.
Container volume (m³)	42 (flat loading)/45 (stowage loading)

Model XZ95EV Technical Parameters

Vehicle dimension (mm)	940037504000
Minimum ground clearance	400mm
Battery Capacity	528kWh, LiFePo4
Power motor	Dual motor 900K: 495kW/2000rpm/2380Nm

Key Advantages

Zero emission environmentally friendly operation
60-70% lower energy costs compared to diesel
Reduced maintenance requirements
Lower center of gravity improves stability on slopes
Meets EPA Tier 5/EU Stage V emissions standards
Safe and reliable operation with strong power output
High operation efficiency and comfortable driving experience

Customization Options

Electric mining truck configurations available to meet specific operational requirements.

About ZEV

Headquartered in Chengdu, Sichuan province, China, ZEV is a group company specializing in the development, production, sales and market application of buses and coaches. Since its foundation in 2006, ZEV's culture of continuous innovation has made it a leading manufacturer in China.

With two production plants and annual capacity of 25,000 units, ZEV offers a 5m-18m product lineup of battery electric buses and coaches. In 2022, ZEV was awarded 825 units of 12m full electric city buses for Chengdu Transport Cooperation, with 400 units serving during the 31st FISU World University Games.
